Cat6 Shielded Direct Burial CMX - Gel Filled, 23AWG
Cat6 Shielded Direct Burial CMX - Gel Filled, 23AWG
cat6 shielded direct burial cable
  • SKU: TSD2404N70B41

Cat6 Shielded Direct Burial CMX - Gel Filled, 23AWG

$295.00 $324.00
UL Listed
Fast, Free Shipping
25 Year Warranty
DESCRIPTION

Experience reliable outdoor connectivity and protection with our Cat6 F/UTP Direct Burial Cable, designed for high-performance data transmission in challenging environments. Built with 24AWG solid bare copper conductors and an overall foil shield with a tinned copper drain wire, this cable offers superior protection against electromagnetic interference (EMI) while maintaining stable gigabit speeds over long distances. The gel-filled waterproof core and sunlight-resistant polyethylene jacket provide exceptional durability against moisture, UV exposure, and temperature changes, making it ideal for direct burial installations without conduit. A cross filler design ensures pair stability and reduces crosstalk for clean, consistent performance up to 400 MHz. Compliant with ANSI/TIA-568.2-D and ISO/IEC 11801 standards, this Cat6 outdoor shielded cable is the dependable choice for data, video, and PoE applications across homes, offices, and commercial environments.

Features
  • Designed for outdoor installations — built to withstand moisture, sunlight, and underground conditions
  • 1000 ft length ideal for long distance or large scale network runs
  • Overall foil shield (F/UTP) with tinned copper drain wire protects against EMI and signal interference
  • Gel-filled waterproof core for maximum protection against moisture and corrosion
  • Sunlight and UV resistant CMX-rated jacket ensures long-lasting outdoor durability
  • 24AWG solid bare copper conductors deliver superior signal strength and stable performance
  • Meets ANSI/TIA-568.2-D and ISO/IEC 11801 standards for dependable, high-speed connectivity
SPECIFICATION
Brand Elite
Category Cat6
Jacket Polyethylene (PE)
Wire Gauge 24AWG
Shielding Shielded
Frequency 400MHz
Twisted Pairs 4
Structure F/UTP
Drain Wire Yes
Rip Cord No
Cable O.D. 8.2 ± 0.3 mm
Conductor Solid bare copper
Conductor O.D. 0.99–1.01 ± 0.02 mm (with insulation)
Storage & Shipping Temp -20°C to 75°C
Installation Temp 0°C to 60°C
Operation Temp -20°C to 75°C
Bending Radius 8 X Overall Diameter
PoE IEEE 802.3af,at,bt | PoE, PoE+, PoE++
Applications 1000 Base-T, 1000Base-TX and Legacy Speeds
Made in Thailand
Length 1000 Feet
Weight 35 lbs.

Downloads

Specification Download

Certifications:

Infinity Cable Products prides itself on offering the highest quality products possible. Our Cat6 Shielded Direct Burial CMX Outdoor F/UTP cable is tried and tested to ensure performance and compatibility.



cat6e unshielded outdoor direct burial
